Zirconia-Corundum Casting Castables

Chrome corundum castables (also called zircon corundum castables, zirconia corundum castables, or chromium corundum castables) belong to the series of composite corundum castables. is made of a-Al2O3, Zr2O3, and zirconium corundum clinker as materials, zircon corundum castables are produced by mixing, molding, drying, and sintering at high temperatures in a shuttle kiln. Zircon corundum castables are a new type of top-grade unshaped refractory material. Refractory castables can be used in a 2000-degree high-temperature kiln, the effect is obvious. Refractory chrome corundum castables are more than double the service life of traditional corundum castables.

Send Email Inquiry Now

Introduction of Zirconia-Corundum Casting Castables

Chrome corundum castables is a kind of high-grade refractory construction material, it is widely used in parts of carbon black reaction furnaces, coal water slurry gasifiers, incinerators, smelting furnaces, steel-making furnaces, glass drawing furnaces, etc. Chrome corundum castables have good properties of high strength & stable thermal shock resistance & excellent performance. There are for sale cheap chrome corundum refractory castables in our company. As one refractory manufacturer, we can provide chrome corundum refractory castables specification and category as well as competitive prices & high-grade quality refractory castables products.

Properties of Zirconia-Corundum Casting Castables

1. Refractory chrome corundum castables have high strength, stable thermal shock resistance, and excellent performance.

2. Chrome corundum refractory castables have the characteristics of good volume stability, high strength, good wear resistance, corrosion resistance, erosion resistance, no cracking, and no peeling.

3. Chrome corundum castables are easy to construct and can be poured on-site or made into prefabricated parts.

4. Chrome corundum refractory castables have the least wear loss, high strength, arbitrary shape control, strong integrity, simple construction, good construction performance, and high-strength wear-resistant refractory castables that can be used by adding water and stirring on site.

Characteristics of Zirconia-Corundum Casting Castables

1. Raw refractory material is corundum and baddeleyite eutectic, with high compression strength.

2. Top high-temperature capability.

3. Excellent thermal stability.

4. Low thermal conductivity.

5. Powerful penetrating-proof capability.

6. Good erosion resistance.

7. Strong resistant erosion stability to the glass liquid.

Application of Zirconia-Corundum Casting Castables

1. Refractory chrome corundum castables are used in various high-temperature furnaces such as carbon black reactors, coal water slurry gasifiers, incinerators, smelting furnaces, steelmaking furnaces, and glass drawing furnaces.

2. Chrome corundum refractory castables are used in carbon black reactors, iron alloy furnaces, and coal water slurry gasifiers, the effect is very significant.

3. Refractory chrome corundum castables should be used as the lining material for various kilns such as boilers, blast furnaces hot blast stoves, heating furnaces, and ceramic kilns.

4. The melting furnace mainly uses ultra-high temperature zircon corundum brick or zircon corundum castables as the lining.

5. Refractory chrome corundum castables application in the carbon black plant carbon black reaction furnace, petrochemical kiln, heating furnace, garbage incinerator, non-ferrous metal smelting furnace, and iron hook material.

Chemical & Physical Index

Item\ Property		Chrome Alumina Castables		Chrome Corundum Castables
		XHJALCR-60	XHJALCR-65	XHJCRCO-70	XHJCRCO-75	XHJCRCO-80
Max working temp.(℃)		1600	1630	1700	1700	1700
Bulk density after drying at 110℃, g/cm3		2.9	2.92	2.95	3	3.1
Chemical analysis, %	Al₂O₃≥	60	65	70	75	80
Chemical analysis, %	Zr₂O₃≤	10	10	5	5	5
Modulus of Rupture (Mpa)	110℃*24H	8	8	12	12	12
Modulus of Rupture (Mpa)	1500℃*3H	14	14	14	14	16
Cold crushing	110℃*24H	110	110	100	100	100
	110℃*24H	110	110	100	100	100
	1500℃*3H	110	120	140	150	165
Linear change after heating, %	1500℃*3H	-0.50%	-0.50%	-0.30%	-0.30%	-0.20%
Water Addition		5-7%	5-7%	4-6%	4-6%	4-6%
Construction method		Vibration	Vibration	Vibration	Vibration	Vibration
Application		Hazardous waste incinerator, rotary kiln lining	Hazardous waste incinerator, rotary kiln lining	Hazardous waste incinerator, rotary kiln lining	coal water slurry gasifier， Hazardous waste incinerator, rotary kiln lining	Melting furnace, carbon black reaction furnace
